Grub screws and threaded rods: Technical perfection from Güldner
Grub screws and threaded rods are fasteners that are used in a wide range of applications. They are small but mighty and play a crucial role in the world of mechanics and mechanical engineering.
A grub screw, also known as a set screw, is a type of screw that is mainly used to fix the position of a machine part. It has no head, which means that it is screwed completely into the material into which it is inserted. This allows for a smooth surface without a screw head protruding. Set screws are often used in applications where space is limited or where the screw head should not be visible. Despite their small size, grub screws play a crucial role in many mechanical systems. They are specifically designed to be inserted into pre-drilled holes and provide a secure and strong connection that can withstand high loads.
A threaded rod, also known as a dowel pin or clamping screw, is a cylindrical metal pin with an internal thread. It is used to hold two or more parts together. Unlike a grub screw, a threaded rod does not have a thread along its entire length, but only at one end. This allows for a stronger connection as the unthreaded part of the pin engages with the material, providing a more secure connection.
Although grub screws and threaded rods have different applications, they are both indispensable tools in the world of mechanics and mechanical engineering. They offer simple but effective solutions for fastening and positioning machine parts, helping to improve the efficiency and performance of machinery and equipment.
In the world of fasteners, grub screws and threaded rods are small but powerful tools that have a big impact. They are essential for many different types of machinery and equipment and help to keep them running smoothly.
The image shows a grub screw M12x30 in accordance with ISO 4029 made of austenitic steel (A4).
Advantages of grub screws and threaded rods
The advantages of grub screws and threaded rods are manifold. They offer...
- strong and durable connections
- easy assembly and disassembly
- compact size
- use in confined spaces
In addition, they are available in a variety of materials and sizes to meet the specific requirements of different industrial applications.
The picture shows a grub screw M12x25 to ISO 4028 made of stainless and acid-resistant stainless steel (A4-70).
Areas of application for grub screws and threaded rods
The following examples show how versatile grub screws and threaded rods are and how they can be used in a wide range of industries and applications.
Mechanical engineering
Grub screws and threaded rods are often used to fasten gears, levers or other machine parts to a shaft. They can also be used to fix the position of one part in relation to another. Similar to grub screws, threaded rods are also used in mechanical engineering to fasten and position machine parts.
Electronics
In electronics, grub screws are often used to fasten components such as potentiometers or rotary knobs.
Automotive industry
Grub screws are often used in the automotive industry to hold together parts such as engines, gearboxes or brakes.
Construction
In the construction industry, threaded rods are often used to securely hold steel beams or other heavy components together.
Furniture construction
Grub screws can also be used in furniture construction to attach handles or knobs to drawers or cupboard doors.
Experience the superior quality and performance of our threaded rods and grub screws at Sonderschrauben Güldner. Your project deserves the best!
Discover the difference when you choose the right manufacturer of threaded rods and grub screws. With us you benefit from:
- Quality: Our products, manufactured according to DIN standards or specific customer requirements, stand for the highest quality standards.
- Flexibility: We offer customized solutions that are perfectly tailored to your individual requirements.
- Reliability: By using high-quality materials and precise manufacturing techniques, we guarantee maximum reliability.
- Experience: Benefit from our many years of experience and our comprehensive expertise in the field of fasteners. Your projects deserve only the best!
Do you need help choosing the right grub screws or threaded rods?
We are at your disposal both online and by telephone. Do not hesitate to contact us! You can send us an e-mail or give us a call at any time.
We look forward to assisting you!
Grub screws and threaded rods: Standards at a glance
There are various standards for grub screws and threaded rods. These standards define the specific properties and requirements for each type of screw, including dimensions, material, hardness and surface treatment. It is important to choose the right standard for your specific application to ensure a secure and reliable connection. At Sonderschrauben Güldner, we ensure that our products comply with these standards to provide the highest quality and performance. Here are some examples:
ISO 4026 (DIN 913) is an internationally recognized standard that defines specific requirements for grub screws with hexagon socket and tapered head.
The ISO 4026 standard sets out the exact specifications for the manufacture of such grub screws, including the size of the hexagon socket, the shape of the cone and the type of material used.
Threaded rods and grub screws manufactured to the ISO 4026 standard are of great importance to many industries, including mechanical engineering, automotive and electronics. They provide a reliable and effective solution for fastening and securing components in a wide range of industrial applications.
ISO 4027 (DIN 914) is a globally recognized guideline that defines the standards for threaded rods with hexagon socket and point.
The ISO 4027 standard defines the precise requirements for the production of these special grub screws. These include the dimensions of the hexagon socket, the design of the tip and the selection of the material to be used.
Such grub screws and threaded rods produced in accordance with the ISO 4027 standard are suitable for a wide range of applications.
ISO 4027 grub screws are indispensable in a variety of industries, including mechanical engineering, automotive and electronics.
ISO 4028 (DIN 915) is a globally accepted standard that defines the criteria for grub screws with hexagon sockets and studs.
This special type of grub screw is indispensable in numerous industries such as mechanical engineering, the automotive industry and electronics.
ISO 4028 specifies the precise requirements for the manufacture of this particular type of grub screw. This includes the dimensions of the hexagon socket, the design of the stud and the choice of material to be used.
Threaded rods and grub screws according to ISO 4028 offer a robust and efficient method for fastening and securing components in various applications.
ISO 4029 (DIN 916) is a globally applicable guideline that defines the standards for threaded pins with hexagon socket and cup point.
These specific grub screws, often referred to as threaded rods, are of great importance in a number of industries, including mechanical engineering, the automotive industry and electronics.
The ISO 4029 standard specifies the exact criteria for the manufacture of this particular type of threaded rod. This includes the dimensions of the hexagon socket, the design of the cup point and the choice of material to be used.
Threaded rods and grub screws produced in accordance with the ISO 4029 standard are suitable for a wide range of applications. They provide a stable and effective method of fastening and securing components in various applications.
The internationally valid guideline ISO 4766 (DIN 551) defines the specifications for grub screws with slot and tapered head.
Grub screws according to ISO 4766 are of central importance in industries such as automotive, electronics and mechanical engineering.
ISO 4766 defines the exact criteria for the production of these fasteners. Among other things, it includes the dimensions of the slot, the design of the tapered head and the material to be used.
The ISO 7434 standard specifies technical details and special properties of grub screws (often also called threaded rods) with a point and slot.
ISO 7434 provides guidelines for the design, manufacture and testing of grub screws. The threaded pins and grub screws therefore meet the required specifications for various industrial applications.
This standard specifies the properties of grub screws and threaded bolts with standard threads M1.6 to M12 and with product class A as well as with slot and tang made of steel and stainless steel.
Setscrews and grub screws to ISO 7435 are provided with a slotted drive at one end. With these types of fasteners, the screw thread extends over the entire length of the grub screw.
The ISO 7436 standard specifies the properties of grub screws or threaded rods with slot and cup point for thread sizes from M1.6 to M12 in product class A.
Grub screws manufactured in accordance with this standard are provided with a slotted drive at one end.
Customized grub screws and threaded rods for specific applications
The individuality of your projects is our main concern. We recognize that each application has its own uniqueness and specific requirements. Therefore, we not only offer an extensive selection of standard grub screws and threaded rods, but also the option to receive customized grub screws and threaded rods that are specifically tailored to your requirements.
Our expertise enables us to respond flexibly to your needs, whether in terms of special materials, deviating standards or special lengths. We are dedicated to producing set screws and grub screws that are manufactured to your exact specifications. This means you can be sure that the grub screws are ideally suited to your application and deliver the desired performance.
Trust in quality and accuracy - choose our Stud Bolts for your demanding projects.
